| Dimensions | 760 x 475 x 340 mm / 2.5 x 1.6 x 1.1 ft mm |
|---|---|
| Support surface | 345 x 730 mm |
| Maximum cutting width 90°/45° | 305 / 205 mm // 12 / 8 1/16 " mm |
| Maximum cutting depth at 90°/45° | 65 / 36 mm // 2 9/16 / 1 13/32 " mm |
| Cutting capacity 90°/90° | 305 x 65 mm / 12 x 2 1/2 " mm |
| Cutting capacity 45°/45° | 205 x 36 mm / 8 1/16 x 1 13/32 " mm |
| Turntable setting left/right | 47 / 47 ° |
| Saw blade tilt left/right | 47 / 2 ° |
| Saw blade | 216 x 30 mm / 8 1/2 x 1.181 " mm |
| Rated input power S1 100% | 1200 W |
| Rated input power S6 20% | 1500 W |
| No-load speed | 5000 rpm |
| Revolutions at rated load | 3750 rpm |
| Cutting speed | 57 m/s / 187 ft/s m/s |
| Weight | 13.5 kg / 29.8 lbs kg |
| Cable length | 2 m / 7 ft m |
| Noise Emission | Sound pressure level | 97 dB(A) |
| Noise Emission | Sound power level (LwA) | 104 dB(A) |
| Noise Emission | Uncertainty of measurement K | 3 dB(A) |
