Unleash Powerful & Precise Metal Drilling with the Metabo MAG 50 Magnetic Core Drill!
- Magnetic core drill with large depth of feed, therefore suitable for use of core drills, spiral drills and countersinks
- Magnetic base with high holding power permits working on vertical surfaces and overhead
- Robust Metabo marathon motor with internal wiring for long service life
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Clockwise/anti-clockwise rotation with thread cutter
- Durable two-speed gearbox with oil bath lubrication for ideal speeds
- Integrated coolant container for easy to dose internal cooling of the core drill
- Bright LED light for easy alignment in poor light conditions
- Swarf protection can be fixed without tools and protects the user from metal shavings and tool contact
- Protective circuit starts motor only if the magnet is activated
- Overload protection: protects the motor from overheating
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable slide for comfortable tool change
- Handle for easy carrying and lifting
| Rated input power | 1200 W |
| Output power | 620 W |
| Max. drill-Ø with core drill | 50 mm |
| Max. drill-Ø with spiral drill | 20 mm |
| Maximum drilling depth | 50 mm |
| Thread cutting | M 16 |
| No-load speeds | 100 – 250 / 200 – 450 rpm |
| Speeds at rated load | 250 / 450 rpm |
| Tool holder | Morse taper MK 2 / Weldon shaft 19 mm (3/4") |
| Weight | 12.7 kg |
| Cable length | 5 m |
| Torque | 90 / 50 Nm |
| Max. depth of feed | 160 mm |
| Max. magnetic holding force | 12250 N |
| Dimensions of the magnet base | 90 × 190 mm |
| Height carriage lowest position | 457 mm |
| Height carriage topmost position | 610 mm |
| Vibration – Drilling in metal | 2.5 m/s² |
| Vibration uncertainty of measurement (K) | 1.5 m/s² |
| Sound pressure level | 79 dB(A) |
| Sound power level (LwA) | 92 dB(A) |
| Noise uncertainty of measurement (K) | 3 dB(A) |
Get the job done right, anywhere, anytime! Buy your Metabo MAG 50 Magnetic Core Drill today at chavda.com!
Brand
Metabo
Title
Metabo Magnetic Core Drill 1200W 50Mm Mag 50 - 600636500
