FEATURES
• 2.2KW solar inverter designed specifically for water pump applications
• Built-in MPPT solar charger for maximum energy efficiency
• Supports single-phase and three-phase asynchronous motors
• Automatic switching between PV and AC input for continuous operation
• Soft start function to prevent water hammer and extend pump life
• Full protection system with self-diagnosis capability
• LCD display with LED indicators for real-time monitoring
• Remote monitoring via RS-485 communication
• Dry-run and water level protection via float switch support
• Optional remote control panel support
SPECIFICATIONS
• Rated Power: 2200W
• Input Voltage (AC): 220/230/240VAC (±15% to +10%)
• Input Frequency: 47–63Hz
• Nominal DC Voltage: 330VDC
• Maximum DC Voltage: 450VDC
• Start-up Voltage: 120VDC
• MPPT Voltage Range: 120–420VDC
• Number of MPPT Trackers: 1
• Output Voltage: 220/230/240VAC
• Output Current: 14A (single-phase) / 10A (three-phase)
• Efficiency: >97%
• Frequency Precision: ±0.2%
• Motor Compatibility: Single-phase and three-phase motors
• Protection: Phase loss, dry pumping, overload, over-voltage, under-voltage, over-current, surge, over-temperature, short circuit
• Dimensions: 110 x 230 x 342 mm
• Weight: 5 kg
• Protection Rating: IP20
• Communication: RS-232 / RS-485
• Operating Temperature: -20°C to 45°C (full load), up to 60°C with derating
• Humidity: <95% RH (non-condensing)
Brand
LinkQnet
Title
LINKQNET 2.2KW 1PH MPPT SOLAR PUMP CONT WITH AC IN - UPS-SOL-PUMP-2.2KW
