FEATURES
• Accelerated Performance - Delivers over 2,100MB/s read and 1,400MB/s sequential write performance
• Easy Capacity Expansion - Double storage capacity to 24× drive bays with one 12-bay DX1222 expansion unit
• Supports Demanding Applications - Leverage up to 32GB memory, 10/25GbE networking or NVMe SSD Cache to boost read and write speed
SPECIFICATIONS
Performance
• CPU: AMD Ryzen V1500B Quad-Core 2.2GHz, 64-bit
• Hardware Encryption Engine: Yes (AES-NI)
• Memory: 4GB DDR4 ECC UDIMM (Expandable up to 32GB)
Storage
• Drive Bays: 12× 3.5"/2.5" SATA HDD/SSD
• Maximum Drive Bays with Expansion: up to 24× (With Expansion Units)
• Hot-Swap Drives: Yes
• Supported RAID: Basic, JBOD, RAID 0, 1, 5, 6, 10, Synology Hybrid RAID
• Maximum Single Volume Size: 108TB (200TB with Expanded Memory)
Network and Expansion
• LAN Ports: 4× 1GbE RJ45
• PCIe Slot: 1× Gen3 x8 (Supports 10GbE Network Upgrade Card)
• USB Ports: USB3.2 Gen1
• Expansion Port: 1× Mini-SAS HD
Performance and Scalability
• Maximum Concurrent SMB Connections: 1,000+
• Maximum iSCSI Targets: 128×
• Maximum LUNs: 256×
• Maximum Local Users: 2,048×
• Maximum Shared Folders: 512×
Enterprise and Data Protection Features
• Btrfs File System: Snapshot and advanced data integrity
• Snapshot Replication: Yes
• Synology High Availability: Supported
• Virtual Machine Manager: Supported
• Active Backup Suite: Supported
Surveillance Station
• Default Camera Licences: 2×
• Scalable IP Camera Deployment: Suitable for Enterprise Surveillance Environments
Power and Physical
• Power Supply: 250W
• AC Input: 100~240V AC
• Cooling: Dual Fan System
• Dimensions (H × W × D): 270 × 300 × 340mm (Approx.)
• Weight: Approx. 9kg (Without Drives)
Environment
• Operating Temperature: 0~40°C
• Humidity: 5~95% RH
Warranty
• 3-Year Hardware Warranty (Extendable to 5-Years with EW202 or Extended Warranty Plus)
Brand
SYNOLOGY
Title
SYNOLOGY DISKSTATION DS2422+ 12-BAY NAS - AMD RYZEN V1500B 2.2GHZ QUAD-CORE CPU, 4GB RAM, DISKLESS - CAS-NASBOX-DS2422+
