Battery voltage | 3.7 V |
Laser diode | 500 – 540 nm, < 10 mW |
Operating temperature | -10 – 40 °C |
Storage temperature | -20 – 70 °C |
Laser class | 2 |
Working range, value | 30 m |
Working range with receiver | 80 m (radius) |
Accuracy | ± 0.3 mm/m |
Self-levelling range | ± 4° |
Levelling time | 4 s |
Dust and splash protection | IP 65 |
Power supply | 4 x 1.5 V LR6 (AA) 3.7 V Li-Ion battery (3000 mAh) |
Operating time (max.) | 5 h (Li-Ion) and 5 h (4 x AA) in 3-line mode |
Tripod thread | 1/4" 5/8" |
Weight, approx. | 0.93 kg |
Colour of laser line | green |
Projection | 3 x 360° line |
Compatible laser receivers | LR 7 |
