KEY FEATURES \n
-
\n
- Contour Marker consists of an X-shaped frame, calibrated protractor, and a triple jointed marking arm and holder \n
- The holder accepts a soapstone crayon(Included), felt pen or pencil \n
- It is used to layout pipe and structural steel joints \n
- Laterals at any angle, tees, wyes, crosses, elbows-any type or size of joint can be quickly and precisely laid out \n
- Pipe from 38 to 450 mm diameter or structural steel members up to 450mm \n
- It can be used right side up or upside down, depending on the direction of the line to be scribed \n
- The protractor is calibrated on both sides – one in degrees, the other in degrees rise-inches-per-foot-to service any type of \n
- measurement need \n
- The unit comes with a structural adaptor designed to simplify the layout of structural joints, including I-beams, angles, channels, \n
- square tubing and similar shapes \n
- The Contour Marker is made from durable, lightweight aluminium \n
- It requires minimal maintenance, only occasional oiling of the joints, to provide long service life \n
- No more complicated mathematical formulas \n
- No more cut and try \n
- No more needles material waste \n
-
\n
- CODE: CNT1 \n
- BARCODE: 24886073798 \n
- HEIGHT: \n
- LENGTH: \n
- WIDTH: \n
Brand
MTS
Title
CNT1 - CURVOMARK MARKER CONTOUR STD #1
