FEATURES
• Comprehensive Power Protection - Protects connected devices from surges, spikes and power fluctuations
• Automatic Voltage Regulation (AVR) - Boost and buck AVR stabilises voltage for reliable power output
• Built-In Self-Diagnostics - Monitors system health to ensure reliable UPS operation
• Cold Start Capability - Allows the UPS to start directly from battery power when mains power is unavailable
• Off-Mode Charging - Charges the battery even when the UPS is switched off
• Auto Restart - Automatically restarts connected equipment once AC power is restored
SPECIFICATIONS
CAPACITY
• 2000VA / 1200W
INPUT
VOLTAGE
• 230VAC
VOLTAGE RANGE
• 140~300VAC
FREQUENCY RANGE
• 50Hz / 60Hz (Auto-Sensing)
OUTPUT
AC VOLTAGE REGULATION (BATTERY MODE)
• 220V / 230V / 240V ±10%
FREQUENCY RANGE (BATTERY MODE)
• 50Hz ±1Hz or 60Hz ±1Hz
TRANSFER TIME
• Typical 4~8ms, 13ms Max.
WAVEFORM (BATTERY MODE)
• Simulated Sinewave
BATTERY
BATTERY VOLTAGE
• 24V
BATTERY NUMBER
• 2× 9Ah
MAX. CHARGE CURRENT
• 1A
INDICATORS
AC MODE
• Green Light
BATTERY MODE
• Orange Flash
FAULT
• Red Light
PROTECTION
FULL PROTECTION
• Short Circuit
• Overload
• Over-Charge
• Over Discharge
ALARM
BATTERY MODE
• Sounding Every 10 Seconds
LOW BATTERY
• Sounding Every Second
OVERLOAD
• Sounding Every 0.5 Seconds
FAULT
• Continuous Sounding
DIMENSIONS (W × D × H)
• 345 × 148 × 189mm
HUMIDITY
• 0~90% RH @ 0~40°C (Non-Condensing)
NOISE LEVEL
• Less than 40dB
Brand
LinkQnet
Title
LINKQNET 2000VA/1200W,230AC/50HZ,LED DISPLAY,9AH - UPS-INT-2000VA-TG-LQ
