FEATURES
• 4G LTE Connectivity - Share internet access with up to 32× Wi-Fi devices and enjoy download speeds of up to 150Mbps
• Plug-and-Play Setup - Simply insert a SIM card to create your wireless network with no configuration required
• 300Mbps Wi-Fi Speeds - Provides fast 2.4GHz wireless connectivity for smooth browsing, streaming and everyday use
• Maximum Network Coverage - Four external antennas deliver stable connections and wider wireless coverage
• Flexible Router Mode - LAN/WAN port supports wired broadband connection when a 4G network is unavailable
SPECIFICATIONS
WIRELESS
• Network Type:
- FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700MHz)
- TDD-LTE: B38/B40 (2600/2300MHz)
- HSPA+/UMTS: B1/B5/B8 (2100/850/900MHz)
• Wi-Fi Class: N300
• Wi-Fi (2.4GHz): 300Mbps
• Wireless Standards: IEEE 802.11b/g/n
• Frequency: 2.4GHz
RECEPTION SENSITIVITY
• 11g 54M: -74.5dBm
• 11n HT20 MCS7: -73.5dBm
• 11n HT40 MCS7: -70.5dBm
TRANSMISSION POWER
• <20dBm (2.4GHz)
WIRELESS SECURITY
• WPA-PSK
• WPA2-PSK
WIRELESS FUNCTIONS
• Smart Connect
• WPS
• Wireless Schedule
• Wireless Clients Statistics
SOFTWARE
OPERATION MODES
• 3G/4G Router
• Wireless Router
CELLULAR MODE
• 4G Preferred
• 4G Only
• 3G Only
CELLULAR APN
• Data Roaming
• Network Search
• Profile Create
• APN Settings
• ISP File Upgrade
• PIN Management
WAN MODE
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP
DHCP
• Server
• DHCP Client List
• Address Reservation
NAT FORWARDING
• ALG
• Virtual Server
• Port Triggering
• UPnP
• DMZ
PROTOCOLS
• IPv4
• IPv6
DATA SETTINGS
• Data Statistics
• Data Limit
GUEST NETWORK
• 2.4GHz Guest Network
PARENTAL CONTROLS
• Time Control
• Website Filtering
DDNS
• Mercusys DDNS
• DynDNS
• NO-IP
SMS
• Inbox
• New Message
• Outbox
• Drafts
SECURITY
• IPv4 SPI Firewall
• Access Control
• Service Filtering
• IP and MAC Binding
• IPv6 Firewall
SYSTEM SETTINGS
• Time Settings
• LED Control
• Diagnostics
• Firmware Upgrade
• Backup and Restore
• Reboot
• Administration
• System Log
• CWMP Settings
DEVICE MANAGEMENT
• Mercusys App
• Web GUI
TR-069
• Supported
HARDWARE
• Dimensions (W × D × H): 219 × 140 × 32mm
• Interfaces:
- 1× 10/100Mbps LAN/WAN Port
- 3× 10/100Mbps LAN Ports
- 1× Nano SIM Card Slot
• Antenna:
- 2× External 4G LTE Antennas
- 2× External Wi-Fi Antennas
• Button: WPS / Reset Button
• External Power Supply: 9V 0.85A
LED
• Power
• Internet
• LAN
• Signal (3×)
LTE STANDARD
• CAT4
• 150Mbps Download / 50Mbps Upload
ENVIRONMENT
• Operating Temperature: 0~40°C
• Storage Temperature: -40~60°C
• Operating Humidity: 10~90% RH (Non-Condensing)
• Storage Humidity: 5~90% RH (Non-Condensing)
Brand
Mercusys
Title
MERCUSYS 4G LTE 300MBPS ROUTER - NET-MER-MB115-4G
