FEATURES
• High-Performance Storage - Over 260,000 4K random read IOPS and 4,700/2,400MB/s sequential read/write performance
• More Than a Storage Server - Consolidate and host backup or video management systems, virtual machines and more thanks to a
capable 6-Core Intel Xeon Processor
• Supports Heavy Applications - Leverage up to 48GB memory, 10/25GbE networking, Fibre Channel support or NVMe SSD Cache to boost read and write speeds
• Easy Capacity Expansion - Scale up to 36× drive bays with two 12-bay DX1222 expansion units
• Long-Term Support - Backed by Synology's 5-year limited warranty
SPECIFICATIONS
Processor
• CPU: Intel Xeon D-1531 6-Core (12-Thread) 2.2GHz
• Turbo Boost: up to 2.7GHz
• Hardware Encryption: AES-NI
Memory
• Installed Memory: 16GB DDR4 ECC SODIMM
• Maximum Memory: Expandable up to 48GB
Storage
• Drive Bays: 12× 3.5" or 2.5" SATA HDD/SSD (Drives Not Included)
• Hot-Swappable Drives: Yes
• SSD Cache Support: Read/Write cache via M.2 NVMe or 2.5" SATA SSD
Network and Connectivity
• LAN Ports: 1× 1GbE RJ45 (Out-of-Band Management and Data), 2× 1GbE RJ45 (Data Transfer), 2× 10GbE RJ45
• Wake on LAN/WAN: Supported (1GbE Ports Only)
• Out-of-Band Management: Supported (First 1GbE Port)
External Ports
• 2× USB3.2 Gen1
• 2× Mini-SAS HD Expansion Ports
PCIe Expansion
• 1× Gen3 x8 Slot (x8 Lanes)
• Supports NICs, M.2 NVMe Adapter Cards, Fibre Channel HBAs
Physical SPECIFICATIONS
• Dimensions (H × W × D): 270 × 300 × 340mm
• Weight: 9.8kg
Environmental SPECIFICATIONS
• Operating Temperature: 5~40°C
• Storage Temperature: -20~60°C
• Relative Humidity: 5~95% RH
• Maximum Operating Altitude: 5,000m
DSM and Storage Management
• Supported RAID
• Synology RAID F1
• Basic, JBOD
• RAID 0, 1, 5, 6, 10
Volume and Snapshot Limits
• Max. Single Volume Size: 108TB / 200TB
• Max. Internal Volumes: 256
• Max. System Snapshots: 65,536
File System Support
• Internal: Btrfs, ext4
• External: Btrfs, ext4, ext3, FAT32, NTFS, HFS+, exFAT
Networking Protocols
• SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Fibre Channel, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
File Sharing Capacity
• Max. Local Users: 16,000
• Max. Local Groups: 512
• Max. Shared Folders: 512
• Max. Concurrent SMB/NFS/AFP/FTP Connections: 4,000 (up to 10,000 with Memory Expansion)
Virtualisation Support
• VMware vSphere
• Microsoft Hyper-V
• Citrix
• OpenStack
• Kubernetes
Security Features
• Firewall
• Shared Folder Encryption
• SMB Encryption
• FTP over SSL/TLS
• SFTP
• Rsync over SSH
• Login Auto Block
• Let’s Encrypt Support
• HTTPS with Customisable Cipher Suite
Brand
SYNOLOGY
Title
SYNOLOGY DS3622XS+ 12 BAY, 16GB,6-C XEON - DISKLE - CAS-NASBOX-DS3622XS+
