FEATURES

• Superior Range – High power ampli­fiers and high-gain antennas provide enhanced wireless range up to 929 sq m
• Wall-Penetrating Wi-Fi – Enhanced Wi-Fi signal cuts through walls and obstacles, eliminating dead zones
• 3 Modes Functionality – Offers three wireless modes, including Router, Range Extender, and Access Point
• 300Mbps Wireless Speed – Ideal for video streaming, online gaming and VoIP

HARDWARE FEATURES
Interface: 4 10/100Mbps LAN Ports
1 10/100Mbps WAN Port
Button: WPS/Reset Button
External Power Supply: 12VDC / 1A
Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 227.5 x 187.3 x 48.3mm
Antenna: 2x 9dBi Detachable Omni Directional Antenna (RP-SMA)

WIRELESS FEATURES
Frequency: 2.4-2.4835GHz
Signal Rate: 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity270M: -71dBm@10% PER
130M: -74dBm@10% PER
108M: -74dBm@10% PER
54M: -77dBm@10% PER
11M: -91dBm@8% PER
6M: -89dBm@10% PER
1M: -97dBm@8% PER
Transmit PowerCE:
<20dBm(2.4GHz)
FCC:
<30dBm
Wireless Functions: Enable/Disable Wireless Radio, Range Extend, WMM, Wireless Statistics
Wireless: 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK

SOFTWARE FEATURES
Quality of Service: WMM, Bandwidth Control
WAN TypeDynamic IP/Static IP/PPPoE/
PPTP/L2TP/BigPond
Management: Access Control
Local Management
Remote Management
DHCPServer, Client, DHCP Client List,
Address Reservation
Port Forwarding: Virtual Server,Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, Comexe, NO-IP
VPN Pass-Through: PPTP, L2TP, IPSec (ESP Head)
Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security: DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding

OTHERS
Certification: CE, FCC, RoHS, NCC, BSMI
