FEATURES

• Compatible with LTE/HSPA+/HSUPA/HSDPA/UMTS/EVDO USB modems, tested in the field
• 3G/4G and WAN connection Backup guarantees an "Always-online" Internet connection
• Local wireless HD video sharing, with speeds up to 300Mbps
• Easy one-touch wireless security encryption with the WPS button
• Bandwidth control allows administrators to determine how much bandwidth is allotted to each PC

SPECIFICATIONS

HARDWARE FEATURES
• Interface: 1 USB2.0 Port for LTE/HSPA+/HSUPA/HSDPA/UMTS/EVDO USB Modem
• 1 10/100Mbps WAN Port, 4 10/100Mbps LAN Ports, support the auto-Negotiation and auto-MDI/MDIX
• Button: WPS/Reset Button
• Wireless On/Off Switch
• Power On/Off Button
• External Power Supply: 12VDC/1A
• Dimensions ( W x D x H ): 204x 138x 44mm
• Antenna Type: V1&V2 Omni directional, Detachable, Reverse SMA
• V3&V4 Omni directional, detachable, Reverse SMA
• Antenna Gain: 2x 5dBi

WIRELESS FEATURES
• Wireless Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
• Frequency: 2.4-2.4835GHz
• Transmit Power: <20dBm
• Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,
• Wireless MAC Filtering

SOFTWARE FEATURES
• Security: NAT Firewall, SPI Firewall, MAC / IP / Packet / Application / URL Filtering, Denial of Service(DoS), SYN Flooding, Ping of Death
• Management: Web Based Configuration(HTTP), Web Based Firmware Upgrade

OTHERS
• Certification: CE, FCC, RoHS
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista Windows 7, 8, 10, MAC OS, NetWare, UNIX or Linux
