FEATURES

• Supports up to four WAN ports using three configurable WAN/LAN interfaces plus a fixed WAN port, allowing flexible multi-ISP or multi-link connections
• Integrated smart load balancing automatically selects the best path based on bandwidth and load demands
• Advanced firewall with DoS protection and IP/MAC/URL/WEB filtering for defense against common attacks
• Web portal authentication and access control to manage network usage and client access
• Traffic management tools including bandwidth control and session limits for efficient resource allocation
• Auto negotiation on ports and comprehensive protocol support (TCP/IP, DHCP, NAT, PPPoE, etc.)
• Built-in surge protection to safeguard hardware from electrical spikes

SPECIFICATIONS

• Standards supported IEEE 802.3, IEEE 802.3u, IEEE 802.3x; TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS
• Ports 1 fixed 10/100 Mbps WAN port
• Ports 1 fixed 10/100 Mbps LAN port
• Ports 3 changeable 10/100 Mbps WAN/LAN ports
• Network media support 10BASE-T and 100BASE-TX over UTP cat3/4/5/5e cabling
• DHCP server/client with address reservation
• Security functions firewall, IP/MAC/URL/WEB filtering, ALG
• Traffic features bandwidth control, session limit
• Concurrent sessions up to about 10000 connections
• Power supply internal universal AC input (region dependent)
• LED indicators for power, system, WAN, LAN and WAN/LAN statuses
