FEATURES

• Brings Wi-Fi dead zone to life with strong Wi-Fi expansion at combined speed of up to 1.2Gbps
• Operates over both the 2.4GHz band (300Mbps) and 5GHz band (867Mbps) for more stable wireless experience
• Intelligent signal light helps to fi­nd the best location for optimal Wi-Fi coverage by showing the signal strength
• Works with any Wi-Fi router or wireless access point

SPECIFICATIONS

HARDWARE FEATURES
• Standards and Protocols: IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b
• Interface: 1x 10/100Mbps Ethernet Port (RJ45)
• Button: WPS Button, Reset Button
• Power Consumption: 7.3W（max power consumption）
• Dimensions ( W x D x H ): 80x 78x 77mm
• Antenna: 2x external

WIRELESS FEATURES
• Frequency: 2.4GHz & 5GHz(11ac)
• Signal Rate: 5GHz:Up to 867Mbps
• 2.4GHz:Up to 300Mpbs
• Reception Sensitivity: 5GHz:
- 11a 6Mbps:-91dBm@10% PER
- 11a 54Mbps: -74dBm@10% PER
- 11ac HT20 mcs8: -68dBm@10% PER
- 11ac HT40 mcs9: -63dBm@10% PER
- 11ac HT80 mcs9: -59dBm@10% PER
2.4GHz
- 11g 54M: -79dBm@10% PER
- 11n HT20 mcs7: -77dBm@10% PER
- 11n HT40 mcs7: -74dBm@10% PER
• Wireless Modes: Range Extender/Access Point
• Wireless Statistic
• Concurrent Mode boost both 2.4G/5G Wi-Fi band
• Wireless Functions: Wireless Statistic
• Concurrent Mode boost both 2.4G/5G Wi-Fi band
• Access Control
• LED Control
• Domain Login Function
• Wireless Security: 64/128-bit WEP / WPA-PSK / WPA2-PSK
• Transmission Power: <17dBm(2.4GHz), <17dBm(5GHz)

OTHERS
• Certification: CE, FCC, RoHS
• Box Dimensions (W X D X H): 156.5x 101.5x 95mm
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac OS, NetWare, UNIX or Linux.
