FEATURES

• Superior Wi-Fi 6 Speeds - Simultaneous 574Mbps on 2.4GHz and 1,201Mbps on 5.0GHz totals 1,775Mbps Wi-Fi speeds
• High-Performance Connectivity - Guarantee higher network efficiency and lower latency
• Four Gigabit Ports - 4 Gigabit Ethernet ports (1× uplink + 3× downlink) with one downlink port supporting PoE pass-through to provide power for wired devices
• Centralised Management - Integrates into Omada SDN for cloud access and remote management
• Secure Guest Network - Along with multiple authentication options (SMS/Voucher, etc.) and abundant wireless security technologies
• Easy Installation and PoE Support - Easy to install design, compatible with 86mm and EU or US standard junction boxes with 802.3af/at PoE support

SPECIFICATIONS

HARDWARE FEATURES
• Interface:
- 1× Uplink: 10/100/1000Mbps Ethernet Port
- 3× Downlink: 10/100/1000Mbps Ethernet Ports (One Port Supports PoE Out)
• Physical Security Lock: Yes
• Button: Reset
• Power Supply: 802.3af/802.3at PoE
• Power Consumption: 12.5W (Without PoE Out)
• Dimensions: 143 × 86 × 20mm
• Antennas: 2× Dual-Band Internal Antennas
- 2.4GHz: 2× 4dBi
- 5.0GHz: 2× 5dBi
• Mounting: Wall Plate Mounting

WIRELESS FEATURES
• Wireless Client Capacity: 100+
• Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
• Frequency: 2.4GHz and 5.0GHz
• Signal Rate:
- 5.0GHz: up to 1201Mbps
- 2.4GHz: up to 574Mbps
• SSIDs: up to 16× SSIDs (8× per Band)
• OFDMA: Yes
• MU-MIMO: Yes
• Seamless Roaming: Yes
• Band Steering: Yes
• Beamforming: Yes
• Airtime Fairness: Yes
• QoS (WMM): Yes
• Load Balance: Yes
• Rate Limit: Yes
• Wireless Schedule and Reboot Schedule: Yes
• Wireless Statistics: Based on SSID/AP/Client

WIRELESS SECURITY
• Captive Portal Authentication
• Access Control
• Wireless MAC Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Local LAN Port-Based VLAN
• Rogue AP Detection
• 802.1X Support
• Encryption: WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

TRANSMISSION POWER
• CE: ≤20dBm (2.4GHz, EIRP), ≤23dBm (5.0GHz, EIRP)
• FCC: ≤21dBm (2.4GHz), ≤21dBm (5.0GHz)

MANAGEMENT
• Omada App: Yes
• Centralised Management: Omada Cloud-Based Controller, OC300, OC200, Omada Software Controller
• Cloud Access: Yes (Through OC300, OC200, Omada Cloud-Based Controller or Omada Software Controller)
• Email Alerts: Yes
• LED On/Off Control: Yes
• Management MAC Access Control: Yes
• SNMP: v1, v2c
• System Logging: Local/Remote Syslog
• SSH: Yes
• Web-Based Management: HTTP/HTTPS
• L3 Management: Yes
• Multi-Site Management: Yes
• Management VLAN: Yes
• Zero-Touch Provisioning: Yes (Requires Omada Cloud-Based Controller)

CERTIFICATION
• CE
• FCC
• RoHS

ENVIRONMENT
• Operating Temperature: 0~40°C
• Storage Temperature: -40~70°C
• Operating Humidity: 10~90% RH (Non-Condensing)
• Storage Humidity: 5~90% RH (Non-Condensing)
