FEATURES
• AX1800 Dual-Band Wi-Fi 6 - Up to 1201Mbps (5.0GHz) and 574Mbps (2.4GHz) for fast, reliable connectivity
• EasyMesh Support - Seamless roaming with unified network coverage across multiple units
• Gigabit Connectivity - 1× Gigabit WAN/LAN and 2× Gigabit LAN ports for high-speed wired connections
• Wired Ethernet Backhaul - Enables ultra-stable high-speed links between nodes for maximum mesh performance
• Dual-Band Coverage - 2.4GHz and 5.0GHz bands for balanced performance and reduced congestion
• MU-MIMO and OFDMA - Efficient data handling for multiple devices simultaneously
• Self-Healing Mesh - Automatically maintains connection using alternative paths if a link drops
• Flexible Operation Modes - Supports Router Mode and Access Point Mode
• Multiple SSIDs - Up to 4 SSIDs per band for network segmentation
• Advanced Security - WPA/WPA2/WPA3 support for secure wireless connections
• Cloud and Remote Management - TR-069 and app-based management for easy deployment and control
SPECIFICATIONS
HARDWARE
• Interface: 1× Gigabit WAN/LAN Port, 2× Gigabit LAN Ports
• CPU: Dual-Core 1.0GHz
• Antenna: Internal Antennas
• Buttons: WPS and Reset
• Power Supply: 12V 1.0A
• Dimensions: 100 × 100 × 89.5mm
WIRELESS
• Wi-Fi Standard: Wi-Fi 6 (IEEE 802.11ax/ac/n/a 5GHz, 802.11ax/n/b/g 2.4GHz)
• Speed: AX1800 - 1201Mbps (5.0GHz) + 574Mbps (2.4GHz)
• Frequency: 2.4GHz and 5.0GHz
• EasyMesh: Seamless Roaming with Self-Healing and 802.11k/v/r Support
• Wireless Features: MU-MIMO, OFDMA, Beamforming
• Security: WPA/WPA2/WPA3 Personal and Enterprise
NETWORK
• WAN Type: Dynamic IP, Static IP, PPPoE, PPTP, L2TP, Bridge
• Protocols: IPv4 and IPv6
• Multi-SSID: Up to 4 SSIDs per Band
• QoS: WMM Support
• IPTV: IGMP v2/v3 and IGMP Snooping
SOFTWARE AND MANAGEMENT
• Operation Modes: Router Mode and Access Point Mode
• Management: Web GUI, Aginet App, TR-069, TR-181, TR-369
• Features: Parental Control, QoS, Port Forwarding, Address Reservation
• Security: SPI Firewall, DoS Protection, IP and MAC Binding
• VPN: IPSec VPN Support
ENVIRONMENT
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 60°C
• Operating Humidity: 10% to 90% Non-Condensing
• Storage Humidity: 5% to 90% Non-Condensing
GENERAL
• Certifications: CE and FCC
• System Compatibility: Windows, macOS and Linux
• Installation: Desktop Placement
Brand
TP-Link
Title
TP-LINK HX220 AX1800 WHOLE-HOME MESH WI-FI ACCESS POINT (1-PACK) - NET-TL-HX220-1PK
