FEATURES

• Gigabit Wi-Fi 6 Speed for 4K Streaming – 3000Mbps Dual Band Wi-Fi for faster browsing, streaming and downloading, all at the same time
• Flexible Deployment – Supports Passive PoE to carry electrical power and data simultaneously
• Multiple Modes – Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs
• Boosted Coverage – Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals
• Captive Portal – Offers a designed portal page for heightened security and marketing

SPECIFICATIONS

HARDWARE FEATURES
• Interface: 1 Gigabit Port (Supports Passive PoE)
• Button: Power On/Off Button, WPS Button, Reset Button
• External Power Supply: 48V/0.5A
• Dimensions ( W x D x H ): 240×165×43.6mm
• Antenna: 4 Fixed High Performance Antennas

WIRELESS FEATURES
• Wireless Standards: IEEE802.11b/g/n/ax 2.4GHz, IEEE 802.11a/n/ac/ax 5GHz
• Frequency: 2.4GHz and 5GHz
• Signal Rate: 2402Mbps at 5GHz, 574Mbps at 2.4GHz
• Reception Sensitivity 5 GHz:
- 11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm
- 11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm
- 11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm
- 11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm
• 2.4 GHz:
- 11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm
- 11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm
• Wireless Functions: Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control
• Wireless Security: WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions
• Transmission Power: FCC: <23dBm(2.4GHz), <22dBm(5GHz)

SOFTWARE FEATURES
• Quality of Service: WMM
• Operating Modes: Access Point, Range Extender, Client, Multi-SSID
• System Tools: SNMP, Ping Watchdog
• DHCP: Server, DHCP Client List
• Protocols: IPv4, IPv6

OTHERS
• Certification: FCC, RoHS
• System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
• Environment: Operating Temperature: 0°C ~ 40°C
• Operating Humidity: 10%~90% non-condensing
