FEATURES

• 11Gbps Tri-Band Wi-Fi – 5764Mbps (6GHz) + 4324Mbps (5GHz) + 688Mbps (2.4GHz)
• 2.5Gbps Wired Connections – 4× 2.5Gbps ports ensure max flexibility and boosted throughput
• Wireless and Wired Combined Backhaul – Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency
• Multi-Link Operation (MLO) – Simultaneously send and receive data across different bands and channels to increase throughput, reduce latency, and improve reliability
• 320MHz Channels – Double the bandwidth and enables many more simultaneous transmissions at the fastest possible speeds
• Works on the 6GHz Band – Minimizes congestion with greenfield spectrum, delivering robust high-speed connections
• TP-Link HomeShield – Provides comprehensive network protection, robust parental controls, and real-time IoT security
• Universal Compatibility – Backward compatible with all Wi-Fi generations and works with any internet service provider (ISP) and modem

SPECIFICATION

WIRELESS
• Standards and Protocols: Wi-Fi 7
- IEEE 802.11be/ax 6 GHz
- IEEE 802.11be/ax/ac/n/a 5 GHz
- IEEE 802.11be/ax/n/b/g 2.4 GHz
• Wi-Fi Speeds: BE11000
- 6GHz: 5765Mbps (802.11be)
- 5 GHz: 4324Mbps (802.11be)
- 2.4 GHz: 688Mbps (802.11be)
• Wi-Fi Range: Broader Whole Home Coverage: TP-Link Mesh Technology
• Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
• AI-Driven Mesh:
• Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
• 4× High-Performance Antennas (Internal):
• Multiple antennas form a signal-boosting array to cover more directions and large areas
• Tri-Band:
• A newly-opened 6 GHz band brings more bandwidth and faster speeds
• Wi-Fi Capacity: Very High
• Tri-Band
• Distribute devices to different bands for optimal performance
• 2×2 MU-MIMO
• Simultaneously communicates with multiple MU-MIMO clients
• OFDMA
• Simultaneously communicates with multiple Wi-Fi 7 clients
• 6 Streams
• More than enough bandwidth for connected devices
• Working Modes Router Mode
• Access Point Mode
• Advanced Features:
- Multi-Link Operation (MLO)
- 320 MHz Channel
- 4K-QAM
- Multi-RUs
- Works with Alexa and Google Assistant

SECURITY
• Network Security:
- SPI Firewall
- Access Control
• HomeShield Security:
- Real-Time IoT Protection
- Malicious Site Blocker
- Intrusion Prevention System
- DDoS Attack Prevention
- Home Network Scanner
• Guest Network:
- 1× 6 GHz Guest Network
- 1× 5 GHz Guest Network
- 1× 2.4 GHz Guest Network
• Effective Time
• Bandwidth Control
• VPN Server:
- OpenVPN Server
- PPTP VPN Server
- L2TP/IPSec VPN Server
• VPN Client:
- OpenVPN Client
- PPTP VPN Client
- L2TP/IPSec VPN Client
• Wi-Fi Encryption:
- WPA-Personal
- WPA2-Personal
- WPA3-Personal

HARDWARE
• Ethernet Ports:
- 4× 2.5Gbps
• *Per Deco Unit
• Supports WAN/LAN auto-sensing
• USB Support:
- 1× USB3.0 Port
- FTP Server
- Media Server
- Samba Server
• Buttons:
- 1× Reset Button
- 1× WPS

SOFTWARE
• Advanced Features:
- Reboot Schedule
- Tapo/Kasa Onboarding
- IoT network & Device Isolation
- Static Routing Function
- Node/Band Connection Preference
• Protocols:
- IPv4
- IPv6
• Service Kits: HomeShield
• Parental Controls: HomeShield Parental Controls:
- YouTube Restriction
- SafeSearch
- Custom Profiles
- Professional Content Filter Library
- Family Time
- Bedtime
- Off Time
- Time Rewards
- Family Online Time Ranking
- Pause the Internet
- Weekly and Monthly Reports
• WAN Types:
- Dynamic IP
- Static IP
- PPPoE
- PPTP
- L2TP
• Quality of Service:
- HomeShield QoS
• QoS by Device
• Cloud Service:
- OTA Firmware Upgrade
- TP-Link ID
- DDNS
• NAT Forwarding:
- Port Forwarding
- UPnP
• IPTV:
- IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN
• DHCP:
- Address Reservation
- DHCP Client List
- Server
• DDNS: TP-Link
• Management Features: Deco App

OTHER
• Network Services Enabled by Default: Web Server
• Manage and Configure Device Through Web (HTTP/HTTPS)
- Port: 80/443 Protocol TCP
• DNS Port: 53 Protocol TCP & UDP
• DHCP Server
• IP Address Assignment (DHCP)
- Port: 67 Protocol UDP
• App Management
• Manage and Configure Device Through App
- Port: 22 Protocol TCP
- Port: 20001 Protocol TCP
- Port: 30001 Protocol TCP
- Port: 20002 Protocol UDP
• Certifications: CE, FCC, RoHS
• Environment: Operating Temperature: 0°C~40°C
• Storage Temperature: -40°C~60°C
• Operating Humidity: 10%~90% RH
• Storage Humidity: 5%~90% RH

PHYSICAL
• Dimensions (W×D×H): 107.5 × 107.5 × 176mm
