FEATURES

• 3.6Gbps Dual-Band Wi-Fi 7 Speeds - 2,882Mbps on 5.0GHz and 688Mbps on 2.4GHz for fast and reliable connectivity
• 2.5Gbps Wired Connections - 2× 2.5Gbps Ethernet ports deliver higher throughput and flexible wired networking
• Multiple Mounting Options - Supports pole mount, wall mount and tabletop installation
• Built for Outdoor Use - IP65-rated dust and water resistance for reliable outdoor operation
• Power over Ethernet (PoE) - Provides both power and data through a single Ethernet cable
• Hybrid Wireless and Wired Backhaul - Combines wired and wireless backhaul simultaneously for improved performance and lower latency
• Multi-Link Operation (MLO) - Sends and receives data across multiple bands to increase speed and reliability
• Seamless AI-Driven Roaming - Works with Deco mesh to create a unified Wi-Fi network with smooth roaming
• TP-Link HomeShield Security - Advanced network protection, parental controls and IoT security features

SPECIFICATIONS

WIRELESS STANDARDS
• Wi-Fi 7
• IEEE 802.11be/ax/ac/n/a 5.0GHz
• IEEE 802.11be/ax/n/b/g 2.4GHz

WI-FI SPEEDS
• BE3600
• 2,882Mbps at 5.0GHz
• 688Mbps at 2.4GHz

WI-FI RANGE
• TP-Link Mesh Technology
• AI-Driven Mesh
• 4× High-Performance Internal Antennas

WI-FI CAPACITY
• Dual-Band
• OFDMA
• 4 Streams

WORKING MODES
• Router Mode
• Access Point Mode

ADVANCED FEATURES
• Multi-Link Operation (MLO)
• 160MHz Channel
• 4K-QAM
• Multi-RU
• Works with Alexa and Google Assistant

NETWORK SECURITY
• SPI Firewall
• Access Control
• HomeShield Security
• Real-Time IoT Protection
• Malicious Site Blocker
• Intrusion Prevention System
• DDoS Attack Prevention
• Home Network Scanner

GUEST NETWORK
• 1× 5.0GHz Guest Network
• 1× 2.4GHz Guest Network
• Effective Time
• Bandwidth Control

VPN SERVER
• OpenVPN Server
• PPTP VPN Server
• L2TP/IPSec VPN Server
• WireGuard VPN Server

VPN CLIENT
• OpenVPN Client
• PPTP VPN Client
• L2TP/IPSec VPN Client
• WireGuard VPN Client

WI-FI ENCRYPTION
• WPA Personal
• WPA2 Personal
• WPA3 Personal

HARDWARE

ETHERNET PORTS
• 2× 2.5Gbps Ports (Auto-Sensing WAN/LAN)

BUTTON
• Reset Button
• WPS Button

POWER
• Power Input: IEEE 802.3at PoE or 100~240V 50/60Hz 0.5A AC

ADVANCED FEATURES
• Reboot Schedule
• Tapo/Kasa Onboarding
• IoT Network and Device Isolation
• Static Routing Function
• Node/Band Connection Preference

PROTOCOLS
• IPv4
• IPv6

PARENTAL CONTROLS
• YouTube Restriction
• SafeSearch
• Custom Profiles
• Professional Content Filter Library
• Family Time
• Bedtime
• Off Time
• Time Rewards
• Pause the Internet
• Weekly and Monthly Reports

WAN TYPES
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP

QUALITY OF SERVICE
• HomeShield QoS
• QoS by Device

CLOUD SERVICE
• OTA Firmware Upgrade
• TP-Link ID
• DDNS

NAT FORWARDING
• Port Forwarding
• UPnP

IPTV
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN

DHCP
• Address Reservation
• DHCP Client List
• Server

DDNS
• TP-Link

MANAGEMENT
• Deco App

DIMENSIONS (W × D × H)
• 110 × 121.3 × 215.5mm

CERTIFICATIONS
• CE
• FCC
• RoHS

ENVIRONMENT
• Operating Temperature: -30~60°C
• Operating Humidity: 10~90% RH
• Storage Humidity: 5~90% RH
