FEATURES

• Super-Fast Wi-Fi 6 Speeds - 1201Mbps (5.0GHz) and 574Mbps (2.4GHz)
• TP-Link Mesh Technology - Walk throughout your home and stay connected with the fastest possible speeds
• Alexa Built-In - Embrace a smarter home with whole-home voice control via Amazon Alexa
• Integrated Smart Speaker - Supports popular audio providers throughout your home with premium sound
• TP-Link HomeShield - Provides reliable IoT protection, robust parental controls and comprehensive security reports
• Full Gigabit Ethernet - 2× Gigabit WAN/LAN Ethernet ports per Deco Voice unit provides warp-speed wired connections
• Setup Made Easier Than Ever - The Deco App walks you through the setup step-by-step
• Works with All Deco Models - Compatible with all Deco models to form a unified whole-home mesh network

SPECIFICATIONS

SECURITY
• Network Security: SPI Firewall
• Access Control
• HomeShield Security
• Real-Time IoT Protection
• Malicious Site Blocker
• Intrusion Prevention System
• DDoS Attack Prevention
• Home Network Scanner
• Guest Network: 1× 5.0GHz Guest Network
• 1× 2.4GHz Guest Network
• Wi-Fi Encryption: WPA-Personal
• WPA2-Personal
• WPA3-Personal

WIRELESS
• Standards: Wi-Fi 6
• IEEE 802.11ax/ac/n/a 5.0GHz
• IEEE 802.11ax/n/b/g 2.4GHz
• Wi-Fi Speeds: AX1800
• 5.0GHz: 1201Mbps (802.11ax)
• 2.4GHz: 574Mbps (802.11ax)
• Wi-Fi Range: Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
• 2× Antennas (Internal)
• Beamforming
• Wi-Fi Capacity: Dual-Band
• MU-MIMO
• OFDMA
• 4× Streams
• Working Modes: Router Mode
• Access Point Mode

HARDWARE
• Performance: Microphone
• Quadruple microphone array
• Speaker
• 5W full frequency speaker with double bass passive diaphragm
• Ethernet Ports: 2× Gigabit Ports
• Supports WAN/LAN auto-sensing
• Buttons: 1× Reset Button
• 1× Mute Button
• 1× Action Button
• 2× Volume Buttons

SOFTWARE
• Protocols: IPv4
• IPv6
• Service Kits: HomeShield
• Parental Controls: HomeShield Parental Controls
- Custom Profiles
- Professional Content Filter Library
- Family Time
- Bedtime
- Off Time
- Time Rewards
- Family Online Time Ranking
- Pause the Internet
- Weekly and Monthly Reports
• WAN Types:
- Dynamic IP
- Static IP
- PPPoE
- PPTP
- L2TP
• Quality of Service:
- HomeShield QoS
- QoS by Device
• Cloud Service:
- OTA Firmware Upgrade
- TP-Link ID
- DDNS
• NAT Forwarding:
- Port Forwarding
- UPnP
• IPTV:
- IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN
• DHCP:
- Address Reservation
- DHCP Client List
- Server
• DDNS: TP-Link
• Management: Deco App

TEST DATA
• Wi-Fi Transmission Power:
CE
- <20 dBm (2.4GHz)
- <23 dBm (5.0GHz)
FCC:
- <30 dBm(2.4GHz)
- <30 dBm(5.0GHz)

PHYSICAL
• Dimensions (W×D×H): 105 × 105 × 170mm

OTHERS
• System Requirements: Android 5.0 or later, iOS 9.0 or later
*Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information
• Certifications: CE, EAC, FCC, IC, RoHS, RCM
• Environment: Operating Temperature: 0°C~40°C
• Storage Temperature: -40°C~60°C
• Operating Humidity: 10%~90% RH
• Storage Humidity: 5%~90% RH
