FEATURES

• 1000Base-LX SFP Module - Delivers reliable Gigabit fibre network connectivity
• Long-Distance Fibre Transmission - Supports distances up to 20km over single-mode fibre
• 1.25Gbps Data Rate - Provides stable high-speed data transfer
• LC Duplex Connector - Ensures secure and efficient fibre connections
• Single-Mode Fibre Support - Compatible with 9/125μm SMF cabling
• Hot Swappable Design - Install or remove without shutting down equipment
• DDM Support - Digital Diagnostic Monitoring for enhanced network management
• SFP-MSA Compliant - Broad compatibility with industry-standard SFP ports
• Compact Mini GBIC Form Factor - Ideal for switches, routers and media converters

SPECIFICATIONS

STANDARDS AND PROTOCOLS

• IEEE 802.3z
• CSMA/CD
• TCP/IP
• Fibre Type: 9/125μm Single-Mode Fibre
• Connector Type: LC Duplex
• Wavelength: 1310nm
• Data Rate: 1.25Gbps
• Maximum Transmission Distance: 20km
• Power Supply: 3.3V

HARDWARE

• Digital Diagnostic Monitoring (DDM)
• SFP-MSA Compliance
• Hot Swappable Support

OTHER

• Dimensions: 55.4 × 13.7 × 12.9mm
• Operating Temperature: 0~70°C
• Storage Temperature: -40~80°C
• Operating Humidity: 10~90% RH Non-Condensing
• Storage Humidity: 5~90% RH Non-Condensing
• Certifications: FCC, CE

COMPATIBLE WITH

• T3700 Series
• T2700 Series
• T2600 Series
• T2500 Series
• T1700 Series
• T1600 Series
• T1500 Series
• 2/3/5 Series
• MC220L
