FEATURES

• Dual-Band Wi-Fi 5 - Combined wireless speeds up to 1,167Mbps (300Mbps on 2.4GHz + 867Mbps on 5.0GHz)
• Omada SDN Integration - Centralised cloud management via Omada Controller, app or web interface
• Multi-WAN Support - up to 3× WAN ports with load balancing for improved uptime and reliability
• Advanced VPN - Supports IPsec, PPTP, L2TP and OpenVPN for secure remote access
• Gigabit Connectivity - 5× Gigabit ports for high-speed wired networking
• Enterprise Security - Firewall, VLAN, QoS and access control for secure and efficient network management

SPECIFICATIONS

• Wireless Standards: IEEE 802.11a/b/g/n/ac
• Frequency: 2.4GHz, 5.0GHz
• Wi-Fi Speed: up to 300Mbps (2.4GHz) + 867Mbps (5.0GHz)
• Antennas:
 - 2.4GHz: 2× 5dBi Fixed Antennas
 - 5.0GHz: 2× 5dBi Fixed Antennas
• Max. SSIDs: 16× (8× per Band)

INTERFACES AND HARDWARE

• Ports:
 - 1× Gigabit WAN
 - 2× Gigabit WAN/LAN
 - 2× Gigabit LAN
• Button: Reset
• Power Supply: 12VDC 1A
• Flash: 128MB NAND
• DRAM: 256MB DDR3
• Max. Power Consumption: 9W
• Mounting: Desktop / Wall Mount
• Dimensions (W × D × H): 215 × 117 × 31mm

PERFORMANCE

• Concurrent Sessions: 50,000
• New Sessions: 2,028/sec
• NAT Throughput: up to 900Mbps+
• IPsec VPN Throughput: up to 175.5Mbps
• WireGuard VPN Throughput: 71.2Mbps
• OpenVPN Throughput: 16.8Mbps

WIRELESS FEATURES

• Multiple SSIDs: up to 16×
• Wireless Features: Band Steering, Load Balance, Airtime Fairness
• Transmit Power Control: Adjustable
• Advanced Features: VLAN, QoS, Captive Portal, RADIUS

NETWORK AND ROUTING

• WAN Types: Static IP, Dynamic IP, PPPoE, PPTP, L2TP
• DHCP: Server, DHCP Reservation, DHCP Options
• VLAN: 802.1Q VLAN
• Routing: Static Routing, Policy Routing, RIP, OSPF
• NAT: One-to-One, Multi-Net, Virtual Server, Port Triggering

VPN

• Protocols: IPsec, PPTP, L2TP, OpenVPN, WireGuard
• IPsec: up to 6× Tunnels (IKEv1/v2, AES256, SHA)
• OpenVPN: Server/Client (up to 18× Tunnels)
• WireGuard: Supported
• L2TP/PPTP: Server and Client support

SECURITY

• Firewall: SPI Firewall
• Protection: DoS, TCP/UDP/ICMP Flood Defence
• Filtering: IP/MAC/URL Filtering
• Security: ARP Inspection, IP-MAC Binding
• DNS Security: DNSSEC, DoH, DoT

MANAGEMENT

• Management: Omada Cloud, App, Web UI
• Controllers: Hardware and Software Controller Support
• Features: Centralised Management, Remote Monitoring, Alerts
• Maintenance: Syslog, Diagnostics, Config Backup/Restore

ENVIRONMENT

• Operating Temperature: 0~40°C
• Storage Temperature: -40~70°C
• Operating Humidity: 10~90% RH (Non-Condensing)
• Storage Humidity: 5~90% RH (Non-Condensing)
