FEATURES

• Dual Relay Control - Built-in dual relays allow independent control and automation of two connected lights or devices
• Roller Shutter Mode - Use the S112 to control motorised roller shutters with obstacle detection for safer operation
• Matter-Certified Compatibility - Works with Apple Home, Alexa, Google Home, Samsung SmartThings and other Matter-supported platforms
• Energy Monitoring - Track energy consumption of connected devices and estimate electricity costs via the Tapo App
• Smart Control with Bluetooth Setup - Control devices remotely, create schedules and configure easily via the Tapo App with instant Bluetooth setup even without Wi-Fi
• Compact Design with Advanced Protection - The small module fits behind switches or in wall boxes and includes zero-crossing protection and relay failure alerts for improved durability and safety

SPECIFICATIONS

WIRELESS TYPE
• IEEE 802.11b/g/n
• 2.4GHz Wi-Fi
• Bluetooth

OPERATING TEMPERATURE
• -20~40°C

OPERATING HUMIDITY
• 10~90% RH, Non-Condensing

PRODUCT DIMENSIONS
• 44.7 × 40.7 × 16.1mm

ENVIRONMENT
• Indoor Use Only

PACKAGING DIMENSIONS
• 65 × 48 × 22mm

RATED
• 100~250V 50/60Hz
• 6A Resistive
• 1.5A Motor
• 150W LED
• 24~30V DC 6A
• 30~48V DC 1.5A
• 48~60V DC 1A

THIRD-PARTY PLATFORM
• Matter-Certified
• Apple Home
• Alexa
• Google Assistant
• Samsung SmartThings
• IFTTT
