FEATURES

• 6-Month Battery Life - Enjoy long-lasting security with fewer charges, ensuring continuous protection and convenience
• 2K Clarity - Provides finer details and incredible clarity
• 160° Ultra-Wide View - Captures everything from head-to-toe
• Full-Colour Night Vision with Spotlight - Vivid night visibility and security
• Free Detection and Notification - Alerts for person, vehicle, pet and package
• Two-Way Audio - High-quality audio with premium microphone and speakers
• Quick Response - Rapid reaction to any situation
• IP65 Weatherproof - Reliable in all weather conditions
• Local and Cloud Storage - Supports microSD card (up to 512GB) and Tapo Care cloud services

SPECIFICATIONS

IMAGE SENSOR
• 1/3" Progressive Scan CMOS Sensor

LENS
• Focal Length: 1.18mm
• Aperture: F1.8
• Field of View: 160° (Diagonal), 135° (Horizontal), 109° (Vertical)

NIGHT VISION
• 850nm IR LED (7.6m)
• Full-Colour Night Vision

LIGHTING
• Built-In Spotlights

INTERFACE AND BUTTON
• Reset Button
• Doorbell Button
• Anti-Theft Button

VIDEO AND AUDIO

MAX RESOLUTION
• 2K 3MP (2304 × 1296)

FRAME RATE
• 15fps

DIGITAL ZOOM
• 10×

VIDEO COMPRESSION
• H.264

LIVE VIEW
• Yes

IMAGE ENHANCEMENT
• 3DNR
• WDR

AUDIO INPUT AND OUTPUT
• Built-In Microphone and Speaker

AUDIO COMMUNICATION
• Two-Way Audio with Noise Cancellation

STORAGE
• Local Storage: MicroSD Card Slot on Camera (up to 512GB)
• Cloud Storage: Tapo Care Cloud Storage Services (Subscription Required)

DETECTION AND NOTIFICATIONS

SENSOR
• Dual PIR Motion Sensor (FOV: 150° Horizontal)
• Ambient Light Sensor

AI DETECTION
• Person Detection

ACTIVITY ZONES
• Yes

OUTPUT NOTIFICATION
• System Notification
• System Notification with Snapshot (Tapo Care Services)

NETWORK

NETWORK CONNECTIVITY
• Connect via Wi-Fi

WIRELESS CONNECTIVITY
• IEEE 802.11b/g/n, 2.4GHz Wi-Fi

SECURITY

SECURITY FEATURES
• On-Device Machine Learning
• 128-bit AES Encryption with SSL/TLS
• WPA/WPA2-PSK

POWER

POWER SOURCE
• 6400mAh Built-In Rechargeable Lithium-Ion Battery
• Optional Solar Panel: Tapo A201 (Sold Separately)

INPUT VOLTAGE
• Doorbell Battery Pack Adapter Input: 100~240V, 50/60Hz

OUTPUT VOLTAGE
• Doorbell Battery Pack Adapter Output: 5V 1A

GENERAL

SMART INTEGRATION
• Google Assistant
• Amazon Alexa

WEATHER RESISTANCE
• IP65

SYSTEM REQUIREMENTS
• Tapo App: iOS 12.0 or Higher
• Android 4.4 or Higher

MOUNTING OPTIONS
• Stick to a Wall
• Mount to a Wall

DIMENSIONS
• Doorbell Dimensions: 150 × 50 × 38.4mm
• Chime Dimensions: 73 × 54.6 × 48mm

CERTIFICATIONS
• CE
• RoHS
• RCM
• NTRA
• FCC
• EAC
• Triman
• UKCA

ENVIRONMENT
• Operating Temperature: -20~45°C
• Storage Temperature: -40~60°C
• Operating Humidity: 10~90% Non-Condensing
• Storage Humidity: 0~90% Non-Condensing
