FEATURES

• 16-Channel Live View and 4K HDMI Video Output
• Up to 10-ch @ 3MP (25fps) / 16-ch @ 1080p (25fps) Decoding Capability
• 16-Channel Synchronous Playback
• 320Mbps Incoming Bandwidth and 320Mbps Outgoing Bandwidth
• 4× SATA Interfaces and 1 up to 16TB
• H.265+ Compression Technology
• 2× HDMI and 1× VGA Video Output
• Remote Monitoring

SPECIFICATIONS

VIDEO AND PERFORMANCE

• 16-Channel IP Input: Supports up to 16× IP Cameras
• 320Mbps Incoming And Outgoing Bandwidth: High-Capacity Data Throughput
• Up To 8MP Recording Resolution: Crisp High-Definition Video Capture
• HDMI And VGA Outputs: Dual HDMI and VGA with up to 4K Output Support
• 16-Channel Synchronous Playback: Simultaneous Multi-Channel Review

COMPRESSION AND DECODING

• Video Compression: H.265+, H.265, H.264+, H.264
• Audio Compression: G.711A, G.711U, G.726
• Advanced Decoding Capability: Supports Multi-Channel 8MP, 5MP, 4MP and 1080p Streams

STORAGE

• 4× SATA Interfaces: Supports up to 16TB per HDD
• eSATA Interface: Additional External Storage Option
• USB Ports: 2× USB2.0 Front and 1× USB3.0 Rear

NETWORK AND INTEGRATION

• 2× Gigabit RJ45 Ports: 10/100/1000Mbps Self-Adaptive Ethernet
• ONVIF Compatibility: Profile S and G Support
• Remote Access: Web Browser and Android iOS Mobile App
• Network Protocols: Includes HTTP, HTTPS, RTSP, RTP, DHCP, DNS, NTP, UPnP and More...

SMART DETECTION AND ALARM
• Smart Analytics: Motion Detection, Intrusion Line-Crossing, Region Entry and Exit Detection
• Human And Vehicle Detection: Enhanced AI-Based Monitoring
• Anomaly Alerts: Video Loss Disk Exception, Login Exception, IP Conflict
• Alarm Interfaces: 16-in, 4-out with Buzzer and AUDIO ALARM SUPPORT

PHYSICAL AND POWER

• Dimensions: 440 × 330 × 44mm
• Power Supply: 100–240VAC 50/60Hz
• Max Power Consumption: 5.5W without Disk, 45W with Disk
• Operating Temperature: -10~55°C
