FEATURES

• 3MP Super-High Definition: The camera comes with 3MP - more than enough pixels to pick up some of the more discrete details
• 24h Full-Colour: Obtain 24-hour colour details, even in pitch-black conditions, with its large-aperture lens, high-sensitivity sensor and attached supplemental lights
• Human and Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications
• Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera or removes/abandons objects
• Built-In Microphone: Features a built-in microphone to record anything going on within a 4.5m radius of the camera
• IK10 Vandal-Proof and IP67 Waterproof: With vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built tough to withstand vandalism and harsh environments with rain and dust for constant security anywhere and anytime
• H.265+: Without using any extra bandwidth, your camera transmit compressed crystal-clear video to save disk space, ease network load and reduce monitoring costs without sacrificing image quality
• Smart Video Enhancement: VIGI's professional technologies process videos to greatly improve their quality that is vital to your monitoring, including Smart IR, WDR, 3D DNR and Night Vision
• 12V DC/PoE: Two types of power supply not only gives you more convenience but also makes your wiring remarkably easy
• Flexible Management: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app and VIGI Security Manger


SPECIFICATIONS

CAMERA
• Image Sensor: 1/2.8" Progressive Scan CMOS
• Shutter Speed: 1/3 to 1/10000 s
• Slow Shutter: Yes
• Minimum Illumination: Colour: 0.005 Lux; 0 Lux with IR/White Light
• Day/Night Mechanism: IR Cut Filter
• Day/Night Switch: Unified / Scheduled / Auto
• Lens: 2.8mm
• Aperture: 2.8 mm: F1.6
• Lens Mount: M12
• Viewing Angle: 2.8mm
• Horizontal FOV: 107.5°, Vertical FOV:57.2°, Diagonal FOV: 128.7°
• Pan/Tilt Range: Pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360°
• Digital Noise Reduction: 3D DNR, WDR, DWDR
• Weatherproof Rating: IP67

LENS
• Type: Fixed Focal Lens
• Focal Length: 2.8mm
• Aperture: 2.8 mm: F1.6
• FOV: 2.8 mm:
• Horizontal FOV: 107.5°, Vertical FOV: 57.2°, Diagonal FOV: 128.7°
• Lens Mount:M12
• DORI Distance: 2.8 mm:
• Detect: 52m
• Observe: 22m
• Recognise: 10m
• Identify: 5m

VIDEO
• Max. Resolution: 2304 × 1296
• Main Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• Resolution: 2304 × 1296, 2048 × 1280, 1920 × 1080, 1280 × 720
• Resolution: 704 × 576, 640 × 480, 352 × 288, 320 × 240
• Sub-Stream: H.265/H.264
• H.264 Type: Main Profile/High Profile
• H.264+: Main Stream Supported
• H.265 Type: Main Profile
• H.265+: Main Stream Supported
• Video Bit Rate: Main Stream: 256Kbps to 4Mbps
• Sub-Stream: 64Kbps to 512Kbps

ILLUMINATOR
• IR LED: Quantity: 1
