Cordless Shears: USER BENEFITS:
- Very handy and maneuverable cordless sheet-metal shears for burr-free cutting of sheet metal on site
- Maximum cornering ability, for comfortable cutting of narrow radii from 15 mm
- Faster working, thanks to the efficient brushless motor
- Infinitely adjustable cutting speed for individual customization to the given material and task at hand
- Comfortable handling thanks to low weight, slim grip area and switch located on the top
- Blade spacing can be flexibly adjusted to different sheet thicknesses
- Economical four-way reversible blade, with the highest cut quality
- Maximum safety in every cutting direction, thanks to large hand guard
- Electronic overload protection for long service life
TECHNICAL SPECIFICATION:
Type of battery pack |
LiHD |
Battery voltage |
18 V |
Max. sheet thickness |
Steel: 400 N/mm²1.6 mm / 0.0629 " Steel: 600 N/mm21.2 mm / 0.0472 " Steel: 800 N/mm20.7 mm / 0.0275 " Aluminum: 250 N/mm22 mm / 0.0787 " |
Strokes in idle |
1350 – 4840 rpm |
Cutting speed |
7 m/min / 275 inch/min |
Starting hole diameter |
27 mm / 1.0629 " |
Smallest curve radius |
15 mm / 0.5905 " |
Weight (including battery pack) |
1.9 kg |
Vibration Cutting of Sheets |
7.6 m/s² |
Vibration Uncertainty of Measurement K |
1.5 m/s² |
Noise Emission Sound Pressure Level |
74 dB(A) |
Noise Emission Sound Power Level (LwA) |
85 dB(A) |
Noise Emission Uncertainty of Measurement K |
3 dB(A) |
Tool Type |
Cordless |
SCOPE OF DELIVERY:
- 2 reversible blades
- without battery pack, without charger
- Feeler gauge
- 2 Hexagonal wrenches
