AUTOMATIC SAFETY CLUTCH.
USER BENEFITS:
- Robust die cast aluminium gear housing for optimum heat dissipation and durability.
- Rotating carbon brush bridge for maximum performance even in anti-clockwise operation.
- Vario (V)-Electronics for working at customised speeds to suit various application materials.
- Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
- Spindle with hexagonal recess for screwdriver bits for working without chuck.
- Suitable for powerful drilling of larger diameters and for stirring thick, liquid-like materials.
TECHNICAL SPECIFICATION:
| Rated input power | 750 W |
|---|---|
| Output power | 470 W |
| Drill Ø steel | 16 mm / 5/8 " |
| Drill-Ø soft wood | 50 mm / 2 " |
| No-load speed | 0 – 660 rpm |
| Revolutions at rated load | 350 rpm |
| Gears | 1 |
| Maximum torque | 75 Nm / 664 in-lbs |
| Collar diameter | 43 mm / 1 11/16 " |
| Chuck capacity | 1.5 – 13 mm // 1/16 – 1/2 " |
| Drill spindle with hexagonal recess | 6.35 mm / 1/4 " |
| Drill spindle thread | 1/2 " – 20 UNF |
| Weight (without power cable) | 2.6 kg / 5.7 lbs kg |
| Cable length | 4 m / 13 ft |
| Vibration | Drilling in metal | 2.5 m/s² |
| Vibration | Uncertainty of measurement K | 1.5 m/s² |
| Noise Emission | Sound pressure level | 81 dB(A) |
| Noise Emission | Sound power level (LwA) | 92 dB(A) |
| Noise Emission | Uncertainty of measurement K | 3 dB(A) |
SCOPE OF DELIVERY:
- Geared chuck
- Chuck key
- Long side handle
