- Ejector pin 75 mm
- Safety strap
- Hexagon socket wrench SW 4
- Swarf protection guard
- Transport case
PLASTIC CARRY CASE.
USER BENEFITS:
- Large stroke, therefore suitable for use of core drills, spiral drills and countersinks.
- Magnetic base with high holding power permits working on vertical surfaces and overhead.
- Robust Metabo marathon motor with internal wiring for long service life.
- Integrated coolant container for easy to dose internal cooling of the core drill.
- Bright LED light for easy alignment in poor light conditions.
- Swarf protection can be fixed without tools and protects the user from metal shavings and tool contact.
- Protective circuit starts motor only if the magnet is activated.
- Restart protection: prevents unintentional start-up after power supply interruption.
- Lockable slide for comfortable tool change.
- Handle for easy carrying and lifting.
- Resistant mains cable (5 m) with rubber shroud.
TECHNICAL SPECIFICATION:
| Rated input power | 1000 W |
|---|---|
| Output power | 520 W |
| Max. drill-Ø with core drill | 32 mm / 1 1/4 " |
| Max. drill-Ø with spiral drill | 13 mm / 1/2 " |
| Maximum drilling depth | 50 mm / 2 " |
| No-load speed | 700 rpm |
| Revolutions at rated load | 450 rpm |
| Bit retainer | Weldon shaft 19 mm (3/4") |
| Weight | 11.9 kg / 26.2 lbs |
| Cable length | 5 m / 16 ft |
| Torque | 50 Nm / 443 in-lbs |
| Max. depth of feed | 160 mm / 6 5/16 " |
| Max. magnetic holding force | 12250 N |
| Dimensions of the magnet base | 90 x 189 mm / 3 9/16 x 7 1/2 " |
| Height carriage lowest position | 343 mm / 13 1/2 " |
| Height carriage topmost position | 490 mm / 19 9/32 " |
| Vibration | Drilling in metal | 2.5 m/s² |
| Vibration | Uncertainty of measurement K | 1.5 m/s² |
| Noise Emission | Sound pressure level | 85 dB(A) |
| Noise Emission | Sound power level (LwA) | 98 dB(A) |
| Noise Emission | Uncertainty of measurement K | 3 dB(A) |
SCOPE OF DELIVERY:
